TS-70 Thermal Break Casement Window
A high-performance casement window system designed for residential and mid-rise commercial projects. Features 14mm polyamide thermal break strips, multi-chamber profile design, and triple-seal gasket system for exceptional thermal and acoustic performance.
Technical Specifications
- Profile depth: 70mm (frame), 75mm (sash)
- Thermal break: 14mm polyamide strip (PA66+GF25)
- U-value: —?1.8 W/m²K (with Low-E IG unit)
- Air permeability: Class 9A (EN 12207)
- Water tightness: Class E1050 (EN 12208)
- Acoustic rating: Up to 42 dB (Rw)
- Glazing: 24—?8 mm double/triple IG unit
- Finish: Powder coating, anodizing, PVDF, wood grain
TS-160 Lift & Slide Door
Our flagship lift-and-slide door system, engineered for luxury residential villas and high-end commercial terraces. Supports sash weights up to 400 kg with effortless operation. Floor-level aluminum threshold. Designed for openings up to 6 meters wide.
Technical Specifications
- Profile depth: 160mm (frame), 85mm (sash)
- Max sash weight: 400 kg
- Max leaf width: 3,000 mm
- Max opening width: 6,000 mm
- U-value: —?1.6 W/m²K
- Burglar resistance: RC2 (EN 1627)
- Threshold: Floor-level, ADA compliant
- Handle: Multi-point locking with rose handle
TS-130 Folding Door
A multi-fold door system with ultra-narrow center stiles (47mm) for maximum glass area. Perfect for restaurants, pool areas, terraces, and large openings where seamless indoor-outdoor flow is desired. Up to 7 panels in a single opening.
Technical Specifications
- Profile depth: 130mm (frame), 66mm (sash)
- Center stile width: 47 mm
- Max panels: 7 per opening
- Max panel weight: 80 kg
- U-value: —?1.6 W/m²K
- Water tightness: E750 (EN 12208)
- Finish: All RAL colors, custom colors available
- Stacking: Internal or external
TS-CW Stick Curtain Wall
A structural glazing curtain wall system designed for high-rise commercial buildings. Features concealed drainage, thermally broken profiles, and a variety of glazing options. Suitable for seismic zones and extreme wind loads.
Technical Specifications
- Mullion depth: 140mm, 160mm, 200mm options
- Thermal break: 24mm/34mm polyamide strip
- U-value: —?1.4 W/m²K (with triple glazing)
- Wind load resistance: Class 9 (EN 12210)
- Seismic rating: Designed per IBC/UBC
- Fire resistance: E60/EI30 (ISO 834)
- Glazing: 24-50mm IG units, structural silicone sealed
- Drainage: Concealed, pressure-equalized system
TS-80 Sliding Window
A robust sliding window system with concealed drainage channels, pile brush perimeter seals, and optional fly screen integration. Ideal for apartment buildings, hotels, and commercial projects where cost efficiency and performance are equally important.
Technical Specifications
- Profile depth: 80mm (frame), 35mm (sash)
- Thermal break: Non-thermal / Optional (specify)
- Air permeability: Class 6A (EN 12207)
- Water tightness: Class 750 (EN 12208)
- Glazing: 18—?4 mm IG units
- Locking: Multi-point with mushroom head cams
- Screen: Optional built-in fly screen
- Track: Single or double track
